19BP100BE Ch= SDTS-596

• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1965

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 239996

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• 3HA5 or 3HM5 6KZ8 4BZ6 4BZ6 4BZ6 10GK6 6LN8 4DT6 10CW5 6LN8 6LN8 21JV6 17BE3 1S2 10CW5 19AEP4 or 19ENP4 or 19EGP4

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 60 cycles, 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 19BP100BE Ch= SDTS-596 - Motorola Inc. ex Galvin Mfg.Co

• Shape
• Tablemodel, low profile (big size).

• Notes

• The Motorola 19BP100BE is a 19" b/w TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis SDTS-596, VHF tuner CMTT-393Y, UHF tuner HTT-615 and picture tube 19AEP4, 19ENP4 or 19EGP4. Uses elliptical PM 2.25" x 6.25" speaker.
