• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1956 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 82786

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 6AU6 12AU7 12AU7 6V6GT 6V6GT 5Y3GT

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• 4 Loudspeakers

• from Radiomuseum.org
• Model: 67HFK3 Ch= HS-544 - Motorola Inc. ex Galvin Mfg.Co

• Notes

• Use a 4 speed automatic record changer. Push-pull output stage; color=california mahogany.

• Circuit diagram reference
• Beitman Radio Diagrams Vol. 17, 1957

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 349 Folder 6 Date 3-57)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
