B100W

• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1962 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 235370

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• 6AQ8 or ECC85 6BE6 6BA6 6BA6 6AU6 6AL5 12AX7A 6BM8 or ECL82 6BM8 or ECL82 6CA4 or EZ81

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 60 cycle, 120 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: B100W - Motorola Inc. ex Galvin Mfg.Co

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 24 x 10 x 9 inch / 610 x 254 x 229 mm

• Notes

• The Motorola B100W is an AC operated, 10 tube BC and FM table-model stereo with detachable speakers.

• Net weight (2.2 lb = 1 kg)
• 24 lb 0 oz (24 lb) / 10.896 kg

• Mentioned in
• Folder 669-9

• Literature/Schematics (1)
• - - Manufacturers Literature (Motorola Datasheet 68P60011A85 Dated 4-64)

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Set 669, Folder 9 (669-9), Dec. 1963)

• Author
• Model page created by Rodney Boleyn. See "Data change" for further contributors.
