BC4E Ch= HS-4135

• Paese
• USA (Stati Uniti d'America)

• Produttore / Marca
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Anno
• 1964 ?

• Categoria
• Radio (o sintonizzatore del dopoguerra WW2)

• Radiomuseum.org ID
• 222779

• Immagini
• Schemi

Previous Next

Previous Next

Clicca sulla miniatura dello schema per richiederlo come documento gratuito.

• Numero di tubi
• 7

• Valvole
• 17EW8 or HCC85 12BA6 12BA6 12AU6 12BE6 12AV6 35C5

• Principio generale
• Supereterodina (in generale); ZF/IF 455/10700 kHz; 2 Stadi BF

• N. di circuiti accordati
• 5 Circuiti Mod. Amp. (AM)     7 Circuiti Mod. Freq. (FM)

• Gamme d'onda
• Onde medie (OM) e MF (FM).

• Tensioni di funzionamento
• Alimentazione a corrente alternata (CA) / 60 cycle, 110 to 120 Volt

• Altoparlante
• AP magnetodinamico (magnete permanente e bobina mobile) / Ø 5 inch = 12.7 cm

• Materiali
• Plastica (non bachelite o catalina)

• Radiomuseum.org
• Modello: BC4E Ch= HS-4135 - Motorola Inc. ex Galvin Mfg.Co

• Forma
• Soprammobile con orologio (radio-orologio, radiosveglia).

• Annotazioni

• The Motorola BC4E is an AC operated 7 tube AM/FM clock radio. AM Tuning Range: 535 to 1620 kHz. FM Tuning range: 88 to 108MHz.  Has Qty(1) PM 5" speaker. Has built-in ferrite antenna for AM and a 36" wire for the FM antenna. Uses silicon diode for rectifier in power supply.  Cabinet color is black. Has automatic radio turn-on feature and delayed radio shut-off feature.

  Clock has "Visilite" feature, which consists of two clock faces, one which is seen in daylight, the other seen at night.  Located in the center area of the dial face is a translucent ring which has opaque numerals super-imposed on its back side.  Located behind this center area is a plastic disc which is edge lit by a neon lamp.  The ring and numerals cannot be seen in daylight.  At night, however, the neon-lit plastic disc causes the translucent ring to glow softly and since the clock numerals and hands are silhoutted against it, the time is clearly visible.

  The following models use the same schematic and cabinet but have different cabinet colors:

  Model Number	Cabinet Back Color	Cabinet Front Color
  BC4E	Black	Black
  BC4S	Brown	Brown
  BC4W	White	White



• Riferimenti schemi
• Beitman Radio Diagrams Vol. 25, 1965

• Bibliografia
• Photofact Folder, Howard W. SAMS (Set 733, Folder 9)

• Letteratura / Schemi (1)
• - - Manufacturers Literature (Motorola Datasheet 68P60084A25 Dated 4-64)

• Letteratura / Schemi (2)
• Beitman Radio Diagrams, Vol. 25, 1965 (Pages 66, 67, 68)

• Autore
• Modello inviato da Jose Casas-Avalos. Utilizzare "Proponi modifica" per inviare ulteriori dati.

• Altri modelli

• In questo link sono elencati 4607 modelli, di cui 2964 con immagini e 4106 con schemi.
  Elenco delle radio e altri apparecchi della Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
