RC36

Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1950 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 49403

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: RC36 - Motorola Inc. ex Galvin Mfg.Co
  • Shape
  • Chassis only or for «building in»
  • Notes

  •

    Motorola models RC-36 and RC-36A record changers are three-speed single spot changers, designed to play and automatically change the following records, not intermixed:

    (a)  Ten 12-inch 33-1/3 or 78 RPM records,

    (b)  Twelve 10-inch 33-1/3 or 78 RPM records,

    (c)  Twelve 7-inch 45 RPM records,

    (d)  Twelve 7-inch 33-1/3 RPM records.

  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 21, Copyright 1950
