RC37

Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1951 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 49405

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • - without
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: RC37 - Motorola Inc. ex Galvin Mfg.Co
  • Shape
  • Chassis only or for «building in»
  • Notes

  • The motorola model RC-37 record changer is a three - speed , single-post changer, designed to play and automatically change the following records, not intermixed:
    (a)  Ten 12-inch 33-1/3 or 78 RPM records,
    (b)  Twelve 10-inch 33-1/3 or 78 RPM records,
    (c)  Twelve 7-inch 45 RPM records, or
    (d)  Twelve 7-inch 33-1/3 RPM records.

  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 21, Copyright 1950
  • Literature/Schematics (1)
  • Riders 21-17 to 21-29
