S14M

• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1959

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 152718

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 0

• Valves / Tubes
• 12AX7 12AX7 12AX7 12AX7 EL84 EL84 EL84 EL84 5U4GB

• Wave bands
• - without

• Power type and voltage
• No Power needed / 110 - 120 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: S14M - Motorola Inc. ex Galvin Mfg.Co

• Shape
• Console, Lowboy (legs < 50 %).

• Notes
• The Motorola Model S14M is the right side speaker cabinet for the Motorola model SK14M. Cabinet is Mahogany. This model has Qty(1) 12" PM speaker, Qty(2) 5.25" PM speakers and Qty(1) 5" PM speaker, which make up the right side speaker system of stereo model SK14M.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 8-59, Set 453, Folder 9)

• Literature/Schematics (2)
• - - Manufacturers Literature

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
