TP13EE Ch= HS-66217

Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

Data
Forum
Pictures
Collections

  • Year
  • 1969
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 215576

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 15
  • Semiconductors
  • Main principle
  • Superhet with RF-stage; ZF/IF 455/10700 kHz; 4 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)     10 FM circuit(s)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / 120/6 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: TP13EE Ch= HS-66217 - Motorola Inc. ex Galvin Mfg.Co
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Notes
  • The Motorola model TP13EE is a 15 transistor AM/FM radio. AM Tuning Range: 540 to 1600 kHz. FM Tuning Range: 88 to 108 MHz. Has Qty(1) PM Elliptical 4" x 6" speaker. Also has push-pull output. Uses 120V AC or Qty(6) 1.5V "D" cells. Ferrite antenna used for AM, collapsible monopole antenna used for FM. Earphone jack provided on rear that disconnects speaker for private listening. Motorola model TP14EE uses same schematic and chassis.
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Motorola Datasheet 68P63012A28)
  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
