- Country
- United States of America (USA)
- Manufacturer / Brand
- Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
- Year
- 1948
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 163805
Manufacturers Literature
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 30
- Valves / Tubes
- 6AG5 6J6 6AG5 6AG5 6AG5 6AG5 6AL5 6AU6 6AC7 6BA6 6BA6 6AU6 6S8GT 6V6GT 6SK7 6SH7 6J5 6H6 6AC7 6V6GT 6J5 6BG6 1B3GT 5V4G 6SN7GT 6V6GT 5U4G 5U4G 10BP4 12AT7
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- -Loudspeaker incorporated, but system not known.
- Material
- Wooden case
- from Radiomuseum.org
- Model: VK101M - Motorola Inc. ex Galvin Mfg.Co
- Shape
- Console with any shape - in general
- Notes
- Motorola VK101M;
10" round CRT b/w TV with 13 channel VHF I/III tuner, AM/FM radio.
- Source of data
- - - Manufacturers Literature
- Mentioned in
- Photofact Folder, Howard W. SAMS (4821-14 Set 51 Folder 14)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
