- Country
- United States of America (USA)
- Manufacturer / Brand
- Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
- Year
- 1948 ?
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 99288
EbayCOM usertimo56 Item: 140002094493
EbayCOM usertimo56 Item: 140002094493
EbayCOM usertimo56 Item: 140002094493
EbayCOM usertimo56 Item: 140002094493
EbayCOM usertimo56 Item: 140002094493
EbayCOM usertimo56 Item: 140002094493
From a Motorola's Prospect.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 25
- Valves / Tubes
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet.
- Material
- Wooden case
- from Radiomuseum.org
- Model: VK101 - Motorola Inc. ex Galvin Mfg.Co
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 22 x 40 x 21.5 inch / 559 x 1016 x 546 mm
- Notes
- 10" TV with 13 channel VHF I/III Tuner/FM Radio Band II, AM-MW, different console colors known. Walnut and mahogany.
- Price in first year of sale
- 495.00 $
- Mentioned in
- Photofact Folder, Howard W. SAMS (4821-14 Set 51 Folder 14)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
