VT-73A Ch=TS-4J (late)

• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1949

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 132194

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Wooden case

• from Radiomuseum.org
• Model: VT-73A Ch=TS-4J - Motorola Inc. ex Galvin Mfg.Co

• Notes
• Motorola VT-73A Ch=TS-4J (late); 7" round CRT b/w TV with US standard VHF tuner.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (10/1949 Set 71 Folder 12 (TS-4J late))
