W11RC

• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1958 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 212280

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 105-120 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: W11RC - Motorola Inc. ex Galvin Mfg.Co

• Shape
• Chassis only or for «building in»

• Notes
• Motorola model W11RC is a four speed automatic record changer, part number 59D636296. This record changer is designed to play records at 78, 33-1/3, 45 and 16-2/3 RPM. This record changer operates from 60 cycle AC only. This model is the same as Webcor Model 152, differing in color of external parts and type of phono cartridge used.

• Source of data
• - - Manufacturers Literature

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
