Y21T32MGA Ch= TS-537Y
Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
- Year
- 1957 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 206159
Data taken from Motorola datasheet
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 17
- Valves / Tubes
- 4BC8 5U8 3BZ6 3BZ6 3CB6 6AU8 3AU6 3DT6 5AQ5 7AU7 7AU7 6SN7GTB 12DQ6 19AU4 1B3 5AQ5 21ATP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.25 inch = 13.3 cm
- Material
- Metal case
- from Radiomuseum.org
- Model: Y21T32MGA Ch= TS-537Y - Motorola Inc. ex Galvin Mfg.Co
- Shape
- Tablemodel, with any shape - general.
- Notes
- 21" b/w TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF.
Table model, grained mahogany, metal.
- Source of data
- - - Manufacturers Literature
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 335 Folder 20-S dated 1956)
- Literature/Schematics (2)
- Photofact Folder, Howard W. SAMS (Set 397 folder 4 Production Changes Bulletin 207 dated 5-58)
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
