Y23CK48U Ch= TS-908Y
Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
- Year
- 1964 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 250775
Picture from Motorola Datasheet
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 28
- Valves / Tubes
- 6DS4 6FG7 6EH7 6EH7 6EH7 6BL8 6DT6 6BM8 6AW8 6BH6 6HS8 6CG7 6BL8 6DQ6 6DQ6 6EZ5 6BL8 6AL5 6GH8 6BL8 6BL8 6BL8 6DW4 3A3 1V2 6BK4 6BL8 23EGP22
- Number of Transistors
- 1
- Semiconductors
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 cycles, 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Y23CK48U Ch= TS-908Y - Motorola Inc. ex Galvin Mfg.Co
- Shape
- Console with any shape - in general
- Notes
-
The Motorola 23CK48U is a 23" color TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis TS-908Y, VHF tuner SPTT-336Y, UHF tuner JTT-601 and picture tube 23EGP22. Has moreno cabinet.
- Source of data
- - - Manufacturers Literature
- Literature/Schematics (1)
- - - Manufacturers Literature (Motorola Datasheet 68P65110A81 Dated 11-64)
- Literature/Schematics (2)
- - - Manufacturers Literature (Motorola Datasheet 68P65110A80)
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
