• Country
• New Zealand-Aotearoa

• Manufacturer / Brand
• Mullard (NZ), C. & A. Odlin Co. Ltd. (Odlins); Wellington

• Year
• 1937 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 354664

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 0

• Valves / Tubes
• EK2 EF5 EBF1 EL3 EM1 AZ1

• Main principle
• Superheterodyne (common); ZF/IF 475 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 103-253 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 45A - Mullard NZ, C. & A. Odlin Co.

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 520 x 350 x 200 mm / 20.5 x 13.8 x 7.9 inch

• Notes

• Mullard 45A

  6-valve (including cathode-ray indicator) all wave mantel model receiver.

  See also Philips Model 463A.

  UK export model with New Zealand stations dial.

  Made in Great Britain.

• Price in first year of sale
• 22.00 NZ Guineas

• Mentioned in
• -- Original prospect or advert (Evening Star 22 October 1938 Page 3)

• Author
• Model page created by Brian Stevens. See "Data change" for further contributors.
