618

Mullard (NZ), C. & A. Odlin Co. Ltd. (Odlins); Wellington

Data
Forum
Pictures
Collections

  • Year
  • 1948
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 334380

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superhet with RF-stage; 2 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Line / Batteries (any type) / 230 or 2 x 45, 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: 618 - Mullard NZ, C. & A. Odlin Co.
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 330 x 260 x 130 mm / 13 x 10.2 x 5.1 inch
  • Notes

  • 6-valve AC or battery-powered superhet with RF stage.

    Hard wearing leatherette finish in a wide range of colours.

    Same chassis as Philips 545.

    Batteries;

    2 by Eveready 482, 45 volt.

    Eveready 739, 9 volt.



  • Price in first year of sale
  • 35.00 NZ Pound
  • Literature/Schematics (1)
  • -- Original prospect or advert (Otago Daily Times 16 December 1948 Page 2.)
  • Literature/Schematics (2)
  • Schematic NZVRS
  • Author
  • Model page created by Brian Stevens. See "Data change" for further contributors.
