• Country
• Australia

• Manufacturer / Brand
• Mullard Radio Company (Australia) Ltd.; Sydney

• Year
• 1947

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 186954

• Number of Tubes
• 5

• Valves / Tubes
• UCH4 UF9 UF9 UBL1 UY1

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 1 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• AC/DC-set / 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: MUS1100 - Mullard Radio Company

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 19.25 x 12.5 x 7.75 inch / 489 x 318 x 197 mm

• Notes

• See Philips version, Radioplayer Model 105.

• Price in first year of sale
• 36.85 AUS £

• Circuit diagram reference
• Australian Official Radio Service Manual Vol. VI

• Mentioned in
• Mingay's "Radio Diagram & I.F. Index

• Literature/Schematics (1)
• Australian Official Radio Service Manual AORSM (Volume 6, 1948, Page 321.)

• Author
• Model page created by Stuart Irwin. See "Data change" for further contributors.
