152 TA152 Wooden Cabinet
Murphy Radio Ltd.; Welwyn Garden City
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Murphy Radio Ltd.; Welwyn Garden City
- Year
- 1949–1951 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 333104
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); Export model
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 90-115; 120-130; 140-160; 190-225; 230-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Power out
- 1 W (2 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 152 TA152 [Wooden Cabinet] - Murphy Radio Ltd.; Welwyn
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 360 x 170 x 220 mm / 14.2 x 6.7 x 8.7 inch
- Notes
-
An AC mains 3 band table radio housed in a wooden cabinet. Also available as the Murphy TA152 in a bakelite cabinet which has a different output valve ( 10P14).
- Net weight (2.2 lb = 1 kg)
- 5.1 kg / 11 lb 3.7 oz (11.233 lb)
- Author
- Model page created by Matthew Xenakis. See "Data change" for further contributors.
