- Country
- Great Britain (UK)
- Manufacturer / Brand
- Murphy Radio Ltd.; Welwyn Garden City
- Year
- 1953 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 327172
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 451 kHz
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 90-115; 120-130; 140-160; 190-225; 230-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.9 inch = 20.1 cm
- Power out
- 4.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: TA224 - Murphy Radio Ltd.; Welwyn
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 18.5 x 16 x 8 inch / 470 x 406 x 203 mm
- Notes
-
MW/SW bandspread AC mains table radio with sockets for antenna, earth, gramophone pickup and external loudspeaker. Export model.
- Net weight (2.2 lb = 1 kg)
- 11 kg / 24 lb 3.7 oz (24.229 lb)
- Mentioned in
- -- Schematic (Dated May 1953)
- Author
- Model page created by Uday Kalburgi. See "Data change" for further contributors.
