Transistorised Radiogram A899SR
Murphy Radio Ltd.; Welwyn Garden City
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Murphy Radio Ltd.; Welwyn Garden City
- Year
- 1969 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 331641
- Number of Transistors
- 22
- Semiconductors
- BC114 BC113 BC113 BC114 BC114 BF222 BF222 BF273 BF273 BF273 BC154 BC154 BC153 BC153 BC113 BC113 BC119 BC119 AC128 AC176 AC128 AC176
- Main principle
- Superheterodyne (common); ZF/IF 470/10700 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 200-220; 225-240 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 6 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Transistorised Radiogram A899SR - Murphy Radio Ltd.; Welwyn
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 47.125 x 26 x 16.375 inch / 1197 x 660 x 416 mm
- Notes
-
A transistorised stereo radiogram housed in a wooden console cabinet with a 4 band AM/FM stereo tuner with optional A833 stereo decoder, a 2 x 3 watt amplifier and a Garrard 2025TC autochanger fitted with an Acos GP93/1 cartridge. Two 8 x 5 inch elliptical loudspeakers. DIN socket for tape recording and playback.
The first 5 transistors in the list above are in the optional A833 stereo decoder. A similar chassis is fitted to the Murphy A897SR, Murphy A898SR, Murphy A900SR, Bush SRG141, Bush SRG142 and Bush SRG143 stereo radiograms.
- Net weight (2.2 lb = 1 kg)
- 37.7 kg / 83 lb 0.6 oz (83.04 lb)
- Literature/Schematics (1)
- - - Manufacturers Literature (Bush/Murphy Service manual Murphy A897SR A897SRW A898SR A899SR A900SR and Bush models)
- Author
- Model page created by Howard Craven. See "Data change" for further contributors.
