• Country
• Australia

• Manufacturer / Brand
• Music Masters Radio Co.; Brisbane, Qld

• Year
• 1941/1942

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 311407

• Number of Tubes
• 5

• Valves / Tubes
• EK2G 6U7G 6B6G 6V6GT 5Y3GT

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 220; 240; 260 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Wagner - Music Masters Radio Co.;

• Shape
• Console, Lowboy (legs < 50 %).

• Dimensions (WHD)
• 710 x 870 x 390 mm / 28 x 34.3 x 15.4 inch

• Author
• Model page created by David Tipton. See "Data change" for further contributors.
