• Country
• Japan

• Manufacturer / Brand
• Nakamichi Co.; Tokyo

• Year
• 1986 ??

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 345140

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• PLL, Phase-locked loop

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Mobile Tuner/Cassette Deck TD-400 - Nakamichi Co.; Tokyo

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 178 x 50 x 185 mm / 7 x 2 x 7.3 inch

• Notes

• AM/FM Stereo cassette receiver with an audio preamp.

  Requires a connection to the power amplifier.

  Similar to the TD-300





• Net weight (2.2 lb = 1 kg)
• 1.6 kg / 3 lb 8.4 oz (3.524 lb)

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
