Analog Multimeter MF16-1

Nanjing Electric Meter Works; Nanjing

Data
Forum
Pictures
Collections

  • Year
  • 1965 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 344571

 Technical Specifications

  • Number of Transistors
  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / 1,5 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: Analog Multimeter MF16-1 - Nanjing Electric Meter Works;
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 81 x 116 x 42 mm / 3.2 x 4.6 x 1.7 inch
  • Notes

  • Analog Multimeter with the following ranges:

    DC Voltage: 0,5, 10, 50, 250, 500 V
    AC Voltage: 10, 50, 250, 500 V
    DC Current: 0,5 mA, 10 mA, 100 mA
    R: 1 Ω - 10 kΩ and 100 Ω - 1 MΩ
    C: 100 pF - 30 nF (in range setting 10 V AC, using an additional step-down transformer 220 V~ ⇒ 10 V~)
    dB: -10 - +22 dB (0 dB = 1 mW / 600 Ω
    Internal Resistance: 2000 Ω / V



  • Net weight (2.2 lb = 1 kg)
  • 0.340 kg / 0 lb 12 oz (0.749 lb)
  • Author
  • Model page created by Harald Giese. See "Data change" for further contributors.
