WR9667W

• Country
• Germany

• Manufacturer / Brand
• Neckermann-Versand KG; Frankfurt a.M.

• Year
• 1954 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 106624

• • Brand: Twen Tone

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECC85 ECH81 EF41 EABC80 EM34 EL84

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: WR9667W - Neckermann-Versand KG;

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 495 x 300 x 225 mm / 19.5 x 11.8 x 8.9 inch

• Notes
• Hersteller nicht Körting sondern AWB

• Author
• Model page created by Helmut Rinnerberger. See "Data change" for further contributors.
