• Country
• Germany

• Manufacturer / Brand
• Neumann, Gustav; Creuzburg / Werra (Thür.)

• Year
• 1955 ?

• Category
• Radio module post 1925 (not a part, not a key)

• Radiomuseum.org ID
• 142449

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• EF80 EF80

• Main principle
• Superheterodyne (common); ZF/IF 468/10700 kHz

• Tuned circuits
• 6 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, more than 2 x SW plus FM or UHF.

• Power type and voltage
• Powered by external power supply or a main unit.

• Loudspeaker
• - - No sound reproduction output.

• Material
• Various materials

• from Radiomuseum.org
• Model: Tastenschalter-Superspulensatz TSp 7/56 U3 - Neumann, Gustav; Creuzburg /

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 169 x 45 x 120 mm / 6.7 x 1.8 x 4.7 inch

• Notes
• Sechs-(neun) Kreis AM-FM- Tastenschalter-Superspulensatz für kombinierte AM-FM-Empfänger incl. Bandfilter und UKW-Einheit. Besteht aus AM-Tastensatz TOV56/7 + UKW-Tuner U3a. Ausführung U3a mit 2x EF80, ältere Version U3 noch mit 2x 6AC7. - Mit zusätzlichem AM-Bandfilter = TSp7/56 U3a/8 als AM-8-Kreis-Empfänger.

• Price in first year of sale
• 44.10 M

• Source of data
• -- Original-techn. papers.

• Mentioned in
• Radio und Fernsehen (DDR) (1968, Heft 2, S. 64 (Werbung))

• Author
• Model page created by Dietrich Ehrhold. See "Data change" for further contributors.

• Other Models

• Here you find 23 models, 19 with images and 16 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
