• Country
• Great Britain (UK)

• Manufacturer / Brand
• Nombrex Ltd., Exmouth

• Year
• 1969

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 188291

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• ME4001 2TX320 2N5245 ME4001 ME3011 ME3011

• Main principle
• Transmitter

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Batteries / addl. power jack / 9 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: RF-Signal Generator Model 41 - Nombrex Ltd., Exmouth

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 9.5 x 5.5 x 4 inch / 241 x 140 x 102 mm

• Notes

• The RF signal generator 41 covers 147 kHz to 222 MHz in 8 overlapping ranges:
  147 - 455 kHz
  0.45 - 1.40 MHz
  1.35 - 4.20 MHz
  4.00 - 13.2 MHz
  13.0 - 45.0 MHz
  44.0 - 77.0 MHz
  74.5 - 132 MHz
  115 - 222 MHz
  Inbuilt crystal calibrator, variable modulation frequency and level.

  This device was sold in Germany as the Nordmende Experience 3601 with a different faceplate design

• Net weight (2.2 lb = 1 kg)
• 3.5 lb (3 lb 8 oz) / 1.589 kg

• Price in first year of sale
• 55.00 £

• Source of data
• - - Manufacturers Literature

• Author
• Model page created by Edward Bean. See "Data change" for further contributors.
