• Country
• Germany

• Manufacturer / Brand
• Nora, Aron, Heliowatt; Berlin

• Year
• 1927–1929

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 3771

• Number of Tubes
• 6

• Valves / Tubes
• RE054 RE054 RE064 RE054 RE054 RE154

• Main principle
• TRF without regeneration; 2 Special; 3 AF stage(s); Neutrodyne

• Tuned circuits
• 3 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: EW6 - Nora, Aron, Heliowatt; Berlin

• Shape
• Tablemodel, slant panel.

• Dimensions (WHD)
• 601 x 300 x 238 mm / 23.7 x 11.8 x 9.4 inch

• Notes
• Widerstands-Kopplung; Steilpult.

• Net weight (2.2 lb = 1 kg)
• 10.1 kg / 22 lb 3.9 oz (22.247 lb)

• Price in first year of sale
• 360.00 RM

• Source of data
• Radio-Diehr, Berlin, 1928/1929 / Radiokatalog Band 1, Ernst Erb

• Mentioned in
• Funkgeschichte der GFGF (9072)

• Other Models

• Here you find 633 models, 556 with images and 342 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
