Arabella-Stereo Ch= 5/683 poliert

Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Data
Forum
Pictures
Collections

  • Year
  • 1964/1965
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 25868

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 12
  • Main principle
  • Superheterodyne (common)
  • Tuned circuits
  • 8 AM circuit(s)     12 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110-240 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Arabella-Stereo Ch= 5/683 [poliert] - Nordmende, Norddeutsche Mende-
  • Shape
  • Console with Push Buttons.
  • Dimensions (WHD)
  • 1360 x 800 x 395 mm / 53.5 x 31.5 x 15.6 inch
  • Notes

  • AM-ZF-Bandbreite umschaltbar;
    Stereo-Decoder 184.218.12 eingebaut;
    Stereo-NF-Verstärker mit 2 Gegentakt-Endstufen je 8,5 W;
    Phono-Chassis = Dual 1011.

  • Net weight (2.2 lb = 1 kg)
  • 48 kg / 105 lb 11.6 oz (105.727 lb)
  • Price in first year of sale
  • 1,679.00 DM
  • External source of data
  • Erb
  • Literature/Schematics (1)
  • -- Original-techn. papers.
