Coppelia 57 Ch= 764 + Rfk. Ch= 604
Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Country
- Germany
- Manufacturer / Brand
- Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Year
- 1956/1957
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 20871
Quelle ebay
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 20
- Valves / Tubes
- PCC84 PCF80 EF80 EF80 EF80 EF80 PL83 EF80 EF80 EF80 ECC82 PCL82 ECH81 PL81 PY81 DY86 EF80 PABC80 PL82 MW43-69
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Details
- Changer (Record changer); Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 3 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Coppelia 57 Ch= 764 + Rfk. Ch= 604 - Nordmende, Norddeutsche Mende-
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 1080 x 905 x 580 mm / 42.5 x 35.6 x 22.8 inch
- Notes
-
Fernseh-Chassis = Diplomat 57, jedoch mit Klangregister;
Rundfunk-Chassis = Fidelio 57 3D;
Phono-Chassis = Dual 1003.
- Net weight (2.2 lb = 1 kg)
- 97 kg / 213 lb 10.5 oz (213.656 lb)
- Price in first year of sale
- 1,895.00 DM
- External source of data
- Erb
- Source of data
- HdB d.Rdf-& Ferns-GrH 1956/57
- Literature/Schematics (1)
- -- Original-techn. papers.
