- Country
- Germany
- Manufacturer / Brand
- Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Year
- 1980 ??
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 253165
Titelbild Service Manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220-240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 7 W (undistorted)
- Material
- Various materials
- from Radiomuseum.org
- Model: Ch= F9 781.535 - Nordmende, Norddeutsche Mende-
- Shape
- Chassis only or for «building in»
- Notes
-
Chassis F9 781.535.
Used in various Spectra SK3 Color series models.
Very similar to Thomson ICC1/ICC2 chassis.
