Fernseh-Signal-Generator FSG 957/II (FSG 957/2)

• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1960 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 135242

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• ECC85 EC92 ECH81 150C2

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Fernseh-Signal-Generator FSG 957/II - Nordmende, Norddeutsche Mende-

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 200 x 280 x 380 mm / 7.9 x 11 x 15 inch

• Notes
• Nordmende Fernseh-Signal-Generator FSG 957/II.
  VHF-Kanäle 2-11.
  Einige Röhren mehrfach vorhanden.

• Net weight (2.2 lb = 1 kg)
• 14 kg / 30 lb 13.4 oz (30.837 lb)

• Price in first year of sale
• 595.00 DM

• Mentioned in
• Funk-Technik (FT) (20/1960, S. 712 / Werbeanzeige)

• Author
• Model page created by Otto Kippes † 24.4.17. See "Data change" for further contributors.
