• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1973/1974

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 29256

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 5

• Semiconductors
• BF254 BF254 BF240 BF121 TAA991 TBA641 AA112 2AA112 ZW9,1 ST14_Intermetall B30C300

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 6 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, more than 2 x SW plus FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 220 / 2 × 4,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 2 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: GALAXY-mesa 4404 974.110.B Ch= 774.110 B - Nordmende, Norddeutsche Mende-

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 348 x 185 x 80 mm / 13.7 x 7.3 x 3.1 inch

• Notes

• 5 AM-Kreise + 1 AM-Keramikfilter, 8 FM-Kreise + 2 FM-Keramikfilter. Klangregler, Sprache-Musikschalter.

  Transistor ST14 befindet sich im separaten Netzanschlußgerät TN186.

• Net weight (2.2 lb = 1 kg)
• 2.5 kg / 5 lb 8.1 oz (5.507 lb)

• Price in first year of sale
• 238.00 DM

• External source of data
• Erb

• Mentioned in
• Handbuch VDRG 1973/1974 (S. F21)

• Literature/Schematics (1)
• -- Original-techn. papers.
