• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1964–1966

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 110034

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 11

• Valves / Tubes
• EF184 PCF200 PFL200 PCL86 PCL85 ECC82 ECH84 PL500 PY88 DY86 A59-12W

• Number of Transistors
• 6

• Semiconductors
• AF109 AF106 AF106 AF139 AF139 AF126

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Hanseat CH= C15 - 865.723.00 - Nordmende, Norddeutsche Mende-

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 650 x 505 x 380 mm / 25.6 x 19.9 x 15 inch

• Notes

• VHF/UHF.

  Siehe auch Hamlet

• Net weight (2.2 lb = 1 kg)
• 26 kg / 57 lb 4.3 oz (57.269 lb)

• Price in first year of sale
• 1,098.00 DM

• Source of data
• Handbuch VDRG 1964/1965

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
