• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1981

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 133208

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Hifi Tuner Philharmonic TU 1300 981.143H - Nordmende, Norddeutsche Mende-

• Shape
• Rack

• Dimensions (WHD)
• 440 x 105 x 280 mm / 17.3 x 4.1 x 11 inch

• Notes
• Antenneneingang: FM asym. 75 Ohm, AM asym. und angebaute schwenkbare Rahmenantenne.
  Eingangsempfindlichkeit: FM Mono 0,9µV bei 26dB S/N,
  Stereo 23µV für 46 dB S/N.
  Stationsspeicher: 6, einstellbar mit Schraubendreher.
  Die Empfangsfrequenz wird digital und analog angezeigt.
  AFC ist schaltbar.

• Net weight (2.2 lb = 1 kg)
• 4.2 kg / 9 lb 4 oz (9.251 lb)

• Author
• Model page created by Rudolf Osterkamp. See "Data change" for further contributors.
