• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1979 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 233177

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 20

• Semiconductors
• 2SK168 2SC535 2SC461 2SC1342 2SC2634 2SA733 2SD882 2SC1675 µPC1167 µPC1161C HA1151 LC7259 LB1405 SP8629

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: HiFi - Tuner TU 1300 A 981.142H - Nordmende, Norddeutsche Mende-

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 440 x 100 x 260 mm / 17.3 x 3.9 x 10.2 inch

• Notes

• Halbleiter teilweise mehrfach vorhanden

  Leistungsaufnahme: 12 W

  Empfindlichkeit: FM mono: 1µV   FM stereo: 23µV

• Net weight (2.2 lb = 1 kg)
• 3.7 kg / 8 lb 2.4 oz (8.15 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Michael Salzgeber. See "Data change" for further contributors.
