• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1958/1959

• Category
• Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

• Radiomuseum.org ID
• 100881

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 25

• Valves / Tubes
• PCC88 PCF82 EF80 EF80 PM84 EF80 PCL84 EF80 PCL82 ECL80 ECH81 PL36 PY81 DY86 PCL82 EC92 AW53-80 ECC85 ECH81 EF85 EABC80 EM84 ECC83 EL95 EL95

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Details
• Changer (Record changer); Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Imperator 59 Ch= St59 + Rfk. Ch= 59/630 - Nordmende, Norddeutsche Mende-

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 1210 x 930 x 580 mm / 47.6 x 36.6 x 22.8 inch

• Notes

• Fernseh-Chassis = Konsul 59 Ch= St 59;
  Rundfunk-Chassis = Fidelio 59/3D Ch= 59/630;
  Phono-Chassis = Dual 1004.

• Net weight (2.2 lb = 1 kg)
• 87 kg / 191 lb 10.1 oz (191.63 lb)

• Price in first year of sale
• 1,948.00 DM

• Source of data
• HdB d.Rdf-& Ferns-GrH 1958/59

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
