• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1963/1964

• Category
• Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

• Radiomuseum.org ID
• 108538

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 17

• Valves / Tubes
• PCC88 PCF801 EF183 EF183 EF80 PCL84 EF80 PCL86 ECH84 ECC82 PCL85 EAA91 ECH84 PL500 PY88 DY86 A59-11W or A59-12W

• Number of Transistors
• 2

• Semiconductors
• AF139 AF139

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Record Player (not changer); Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Imperator Stereo Ch= StL 14 - Rft= 3/616 - Nordmende, Norddeutsche Mende-

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 1205 x 910 x 450 mm / 47.4 x 35.8 x 17.7 inch

• Notes

• Fernseh-Chassis = StL 14;
  Rundfunk-Chassis = Rundfunk-Teil Imperator 3/616;
  Phono-Chassis = Dual 1007.

• Net weight (2.2 lb = 1 kg)
• 63.4 kg / 139 lb 10.4 oz (139.648 lb)

• Price in first year of sale
• 1,834.00 DM

• Source of data
• Handbuch VDRG 1963/1964

• Literature/Schematics (1)
• -- Original-techn. papers.
