• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1964/1965

• Category
• Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

• Radiomuseum.org ID
• 110054

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 11

• Valves / Tubes
• PCC88 PCF82 PCL86 ECH84 PCL85 ECH84 ECC82 PL500 PY88 DY86 A59-11W or A59-12W

• Number of Transistors
• 11

• Semiconductors
• AF139 AF139 AF121 AF106 AF121 BFY37 BFY41 AF126 AF126 AC125 AC125

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Details
• Changer (Record changer); Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Imperator-Stereo Ch= Uni 15 865.730.00 - Rft= 4/675 - Nordmende, Norddeutsche Mende-

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 1245 x 915 x 455 mm / 49 x 36 x 17.9 inch

• Notes
• Fernseh-Chassis = Kommodore A59-12W;
  Rundfunk-Chassis = Imperator-Stereo, 7 Röhren, 1 Transistor, 6/10 Kreise, LMKU, Stereo-Decoder, Stereo-NF-Verstärker mit 2 Endstufen je 3 W;
  Phono-Chassis = Elac PW16.

• Net weight (2.2 lb = 1 kg)
• 63.4 kg / 139 lb 10.4 oz (139.648 lb)

• Price in first year of sale
• 2,375.00 DM

• Source of data
• Handbuch VDRG 1964/1965

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
