Isabella-Stereo C Ch= 3/683 D818

Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Data
Forum
Pictures
Collections

  • Year
  • 1962/1963 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 134974

 Technical Specifications

  • Number of Tubes
  • 11
  • Number of Transistors
  • 3
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz; Export model
  • Tuned circuits
  • 8 AM circuit(s)     12 FM circuit(s)
  • Wave bands
  • Broadcast, 2 Short Wave plus FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
  • Loudspeaker
  • 7 or more Loudspeakers
  • Power out
  • 17 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Isabella-Stereo C Ch= 3/683 D818 - Nordmende, Norddeutsche Mende-
  • Shape
  • Console with Push Buttons.
  • Dimensions (WHD)
  • 1340 x 800 x 420 mm / 52.8 x 31.5 x 16.5 inch
  • Notes
  • Stereo NF amplifier 2 x 8.5W, Record changer DUAL 2008, 8 speakers.
  • Literature/Schematics (1)
  • - - Manufacturers Literature

 Collections | Museums | Literature

Collections

The model Isabella-Stereo C is part of the collections of the following members.

 Forum

Forum contributions about this model: Nordmende,: Isabella-Stereo C Ch= 3/683 D818

Threads: 1 | Posts: 5

Hello

I,ve here one  Nordmende Isabelle C console to repair. This console has its radio set  vertically placed on.



First I tried to find the holding screws to remove (extract) this set,  but their screws are not visible at all.

Do you know where are the accessable hold points to remove chassis for this kind of  Nordmende models?

Do you help me to to get the solution to this problem?

Thank you for any helpfull answer .



Best Regards

Mario Coelho





Mario Coelho, 27.Oct.20
