- Country
- Germany
- Manufacturer / Brand
- Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Year
- 1963/1964
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 108535
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 17
- Valves / Tubes
- PCC88 PCF801 EF183 EF183 EF80 PCL84 EF80 PCL86 ECH84 ECH84 ECC82 EAA91 PCL85 PL500 PY88 DY86 A59-11W or A59-12W
- Number of Transistors
- 2
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: Konsul Ch= StL14 - Nordmende, Norddeutsche Mende-
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 650 x 545 x 400 mm / 25.6 x 21.5 x 15.7 inch
- Notes
- VHF/UHF. Technische Daten wie Diplomat (A59-11W), jedoch symetrisches Gehäuse. Anschraubbare Beine gegen Mehrpreis (22,- DM).
- Net weight (2.2 lb = 1 kg)
- 28.5 kg / 62 lb 12.4 oz (62.775 lb)
- Price in first year of sale
- 1,068.00 DM
- Source of data
- Handbuch VDRG 1963/1964
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
