• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1963–1965

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 24953

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECC85 ECH81 EAF801 ECC83 EM84 ELL80

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 6 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110/220 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Mikado-Stereo Ch=4/675 [mattiert] - Nordmende, Norddeutsche Mende-

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 1000 x 790 x 370 mm / 39.4 x 31.1 x 14.6 inch

• Notes
• Stereo-NF-Verstärker mit 2 Endstufen je 3 W; FM-Stereo-Decoder nachrüstbar.
  Phono-Chassis = Elac Miracord 16.

• Net weight (2.2 lb = 1 kg)
• 29.5 kg / 64 lb 15.6 oz (64.978 lb)

• Price in first year of sale
• 649.00 DM

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1963/1964
