Sterling Norma USA

Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Data
Forum
Pictures
Collections

  • Year
  • 1960 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 153576

 Technical Specifications

  • Number of Tubes
  • 5
  • Number of Transistors
  • Main principle
  • Superheterodyne (common); Export model
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 117 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Sterling Norma USA - Nordmende, Norddeutsche Mende-
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 14 x 9 x 8 inch / 356 x 229 x 203 mm
  • Notes

  • Nordmende Sterling Norma USA;
    US export version, FM 88 - 108 MHz, terminals for antennas & phono in. BC dial with CD-marks to indicate the frequencies for Civil Defense.

    Compare with most similar Nordmende Norma III (3) Ch= U208, and German domestic version Nordmende Norma MU.

  • Net weight (2.2 lb = 1 kg)
  • 11 lb 2 oz (11.125 lb) / 5.051 kg
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
