• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1978/1979

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 94662

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 14

• Semiconductors
• ED1502 ED1502 ED1502 ED1602 ED1502 ED1502 ED1502 ED1802 ED1602 ED1602 ED1602 2SB172 2SB324 2SD352

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 5 AM circuit(s)     8 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, more than 2 x SW plus FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 220; (6 × 1,5) Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 1 W (unknown quality)

• Material
• Various materials

• from Radiomuseum.org
• Model: Oxford 505K 9.199H - Nordmende, Norddeutsche Mende-

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 268 x 163 x 71 mm / 10.6 x 6.4 x 2.8 inch

• Notes
• 14 Dioden, 1 LED; Anschlüsse für TA/TB, Ohrhörer; Squelch-Regler.

  UKW: 87,5 - 108 MHz
  KW1: 5950 - 6200 kHz
  KW2: 5800 - 16000 kHz
  MW: 510 - 1640 kHz
  LW: 145 - 260 kHz


• Net weight (2.2 lb = 1 kg)
• 1.7 kg / 3 lb 11.9 oz (3.744 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Daniel Doll. See "Data change" for further contributors.
