Präsident Ch= L71/LL71 - 866.713.00
Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Country
- Germany
- Manufacturer / Brand
- Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Year
- 1966/1967
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 112738
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Number of Transistors
- 28
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Präsident Ch= L71/LL71 - 866.713.00 - Nordmende, Norddeutsche Mende-
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 710 x 500 x 375 mm / 28 x 19.7 x 14.8 inch
- Notes
- VHF/UHF. Auf Wunsch anschraubbare Beine.
- Net weight (2.2 lb = 1 kg)
- 30.5 kg / 67 lb 2.9 oz (67.181 lb)
- Source of data
- Handbuch VDRG 1966/1967
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
