Radio Clock 4000 7.174A

Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Data

Forum

Pictures

Collections

Country
Germany

Manufacturer / Brand
Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Year
1976/1977

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
80443

Schematics

Radio Clock 4000 7.174A; Nordmende, (ID = 117116) Radio — Nordmende, Radio Clock 4000 7.174A (3)

Radio Clock 4000 7.174A; Nordmende, (ID = 117117) Radio — Nordmende, Radio Clock 4000 7.174A (3)

Radio Clock 4000 7.174A; Nordmende, (ID = 117118) Radio — Nordmende, Radio Clock 4000 7.174A (3)

Radio Clock 4000 7.174A; Nordmende, (ID = 117100) Radio — Nordmende, Radio Clock 4000 7.174A (3)

Radio Clock 4000 7.174A; Nordmende, (ID = 117101) Radio — Nordmende, Radio Clock 4000 7.174A (3)

Radio Clock 4000 7.174A; Nordmende, (ID = 117102) Radio — Nordmende, Radio Clock 4000 7.174A (3)

Radio Clock 4000 7.174A; Nordmende, (ID = 117103) Radio — Nordmende, Radio Clock 4000 7.174A (3)

Radio Clock 4000 7.174A; Nordmende, (ID = 117105) Radio — Nordmende, Radio Clock 4000 7.174A (3)

Radio Clock 4000 7.174A; Nordmende, (ID = 117106) Radio — Nordmende, Radio Clock 4000 7.174A (3)

Radio Clock 4000 7.174A; Nordmende, (ID = 117107) Radio — Nordmende, Radio Clock 4000 7.174A (3)
Bitte sch_a - sch_c löschen!

Radio Clock 4000 7.174A; Nordmende, (ID = 1787511) Radio — Nordmende, Radio Clock 4000 7.174A (2)
(c) eBay-231473060491-ronabalona 8.Feb.2015

Radio Clock 4000 7.174A; Nordmende, (ID = 1787512) Radio — Nordmende, Radio Clock 4000 7.174A (2)
(c) eBay-231473060491-ronabalona 8.Feb.2015

Radio Clock 4000 7.174A; Nordmende, (ID = 1787513) Radio — Nordmende, Radio Clock 4000 7.174A (2)
(c) eBay-231473060491-ronabalona 8.Feb.2015

Radio Clock 4000 7.174A; Nordmende, (ID = 1787514) Radio — Nordmende, Radio Clock 4000 7.174A (2)
(c) eBay-231473060491-ronabalona 8.Feb.2015

Radio Clock 4000 7.174A; Nordmende, (ID = 1787515) Radio — Nordmende, Radio Clock 4000 7.174A (2)
(c) eBay-231473060491-ronabalona 8.Feb.2015

Radio Clock 4000 7.174A; Nordmende, (ID = 1787517) Radio — Nordmende, Radio Clock 4000 7.174A (2)
(c) eBay-231473060491-ronabalona 8.Feb.2015

Radio Clock 4000 7.174A; Nordmende, (ID = 1787519) Radio — Nordmende, Radio Clock 4000 7.174A (2)
(c) eBay-231473060491-ronabalona 8.Feb.2015

Radio Clock 4000 7.174A; Nordmende, (ID = 2304149) Radio — Nordmende, Radio Clock 4000 7.174A (1)

Radio Clock 4000 7.174A; Nordmende, (ID = 2304150) Radio — Nordmende, Radio Clock 4000 7.174A (1)

Radio Clock 4000 7.174A; Nordmende, (ID = 2304151) Radio — Nordmende, Radio Clock 4000 7.174A (1)

Radio Clock 4000 7.174A; Nordmende, (ID = 2304153) Radio — Nordmende, Radio Clock 4000 7.174A (1)

Radio Clock 4000 7.174A; Nordmende, (ID = 1227261) Radio — Nordmende, Radio Clock 4000 7.174A (2)

Radio Clock 4000 7.174A; Nordmende, (ID = 117091) Radio — Nordmende, Radio Clock 4000 7.174A (2)
Bild aus Service Manual

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
16

Semiconductors
BF240 BF241 BF254 BF494 BC172 BC212 BC239 BC309 BC338 BC549 AC187 AC188 BD517

Main principle
Superheterodyne (common)

Tuned circuits
5 AM circuit(s) 8 FM circuit(s)

Wave bands
Broadcast, Long Wave, Short Wave plus FM or UHF.

Power type and voltage
Alternating Current supply (AC) / 220 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

Power out
2.4 W (unknown quality)

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: Radio Clock 4000 7.174A - Nordmende, Norddeutsche Mende-

Shape
Tablemodel with Clock ((Alarm-) Clock Radio).

Dimensions (WHD)
314 x 107 x 185 mm / 12.4 x 4.2 x 7.3 inch

Notes
ICs: 4.
Automatische Helligkeitsregelung der Leuchtziffern durch LDR.
Transistoren teilweise mehrfach vorhanden.

Net weight (2.2 lb = 1 kg)
2 kg / 4 lb 6.5 oz (4.405 lb)

Source of data
Handbuch VDRG 1976/1977

Mentioned in
-- Original-techn. papers.

Author
Model page created by Daniel Doll. See "Data change" for further contributors.
