• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1962/1963

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 107569

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 20

• Valves / Tubes
• PCC88 PCF80 EF183 EF183 PCF80 PCL84 EF80 PCL86 ECH84 ECC82 EAA91 ECH84 PL36 PY88 DY86 PCL85 PC88 PC86 EF80 AW59-90

• Main principle
• Superheterodyne (common); ZF/IF 38900 kHz

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Roland Ch= StL13 - 863.730.00 - Nordmende, Norddeutsche Mende-

• Shape
• Console, Lowboy (legs < 50 %).

• Dimensions (WHD)
• 625 x 920 x 415 mm / 24.6 x 36.2 x 16.3 inch

• Notes

• VHF/UHF. Technische Daten wie Konsul Ch= StL13, jedoch Standgerät mit Türen.

• Net weight (2.2 lb = 1 kg)
• 42.5 kg / 93 lb 9.8 oz (93.612 lb)

• Price in first year of sale
• 1,340.00 DM

• Source of data
• Handbuch VDRG 1962/1963

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
