Secam-Decoder-Modul 528.953

• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1973 ??

• Category
• Radio module post 1925 (not a part, not a key)

• Radiomuseum.org ID
• 252045

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Powered by external power supply or a main unit.

• Loudspeaker
• - - No sound reproduction output.

• from Radiomuseum.org
• Model: Secam-Decoder-Modul 528.953 - Nordmende, Norddeutsche Mende-

• Notes

• Secam-Decoder-Modul 528.953.

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
