• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1960/1961

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 103140

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 23

• Valves / Tubes
• PC86 or PC88 PC86 PCC88 PCF82 PM84 EF183 EF80 EF80 EF80 EF85 PCL84 PCF80 EF80 PCL86 PCF80 ECL80 ECC82 PCL82 ECH81 PL36 PY88 DY86 AW53-88

• Conflicting model year with tube data.
• The model date contradicts tube dates. [ PC88 (1961)]

• Main principle
• Superheterodyne (common); ZF/IF 38900 kHz

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Souverän Ch= L11 - Nordmende, Norddeutsche Mende-

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 616 x 885 x 460 mm / 24.3 x 34.8 x 18.1 inch

• Notes
• Standgerät auf Rollen; Technische Daten wie Präsident (61).

• Net weight (2.2 lb = 1 kg)
• 54 kg / 118 lb 15.1 oz (118.943 lb)

• Price in first year of sale
• 1,125.00 DM

• Source of data
• HdB d.Rdf-& Ferns-GrH 1960/61

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
