• Year
  • 1982 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 155470

 Technical Specifications

  • Number of Transistors
  • 97
  • Semiconductors
  • Main principle
  • Superheterodyne (common); none
  • Wave bands
  • Wave Bands given in the notes.
  • Details
  • Video-Taperecorder/-Player; Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 240; Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Spectra - Video - Vision V 100 1.460 H - Nordmende, Norddeutsche Mende-
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 440 x 140 x 330 mm / 17.3 x 5.5 x 13 inch
  • Notes
  • Videorecorder nach dem VHS-System;
    27 IC´s, die Mechanik wird über einen eigenen Mikroprozessor gesteuert, Fernbedienung über Zweidrahtleitung, VHF und UHF Tuner mit Varicap Abstimmung.
  • Net weight (2.2 lb = 1 kg)
  • 9.6 kg / 21 lb 2.3 oz (21.145 lb)
  • Price in first year of sale
  • 2,100.00 DM
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by Thomas Ottstadt. See "Data change" for further contributors.
