• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1964/1965

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 25686

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 12

• Valves / Tubes
• ECC85 ECH81 EF89 EBF89 EMM803 EF80 ECC808 ECC808 ECC82 ELL80 ELL80 ECC81

• Number of Transistors
• 1

• Semiconductors
• AF117

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 8 AM circuit(s)     12 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: Stereo-Steuergerät 3004 Ch= 5/634 [Nussbaum] - Nordmende, Norddeutsche Mende-

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 655 x 270 x 280 mm / 25.8 x 10.6 x 11 inch

• Notes
• Stereo-Steuergerät; eingebauter Decoder; Ferritantenne drehbar. Bandbreite schaltbar; NF-Verstärker mit 2 Endstufen je 8,5 W.
  Gehäuse: Nussbaum, natur mattiert.

• Net weight (2.2 lb = 1 kg)
• 22.6 kg / 49 lb 12.5 oz (49.78 lb)

• Price in first year of sale
• 809.00 DM

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1964/1965

• Mentioned in
• Funkschau (19/1965, S. 529, 530, 531, 532)

• Literature/Schematics (1)
• -- Original-techn. papers.
